Connect to TEKMAND console or TEKMAND onPC
1.3" internal screen
Power Over Ethernet(POE/802.3at)
Support sACN and Artnet protocols
Upgrade software/Configuration port via Artnet
Viewing device status via web
Support DMX frame rate (package rate)setting
Support RDM
4 x DMX512 Out(5pin/3pin XLR female)
2x PoE etherCON/RJ45(10/100/1000M)
Two ethernet port work as network switch
4 x Network signal LEDs
Type-C Power In
Connect to TEKMAND console or TEKMAND onPC
1.3" internal screen
Power Over Ethernet(POE/802.3at)
Support sACN and Artnet protocols
Upgrade software/Configuration port via Artnet
Viewing device status via web
Support DMX frame rate (package rate)setting
Support RDM
4 x DMX512 Out(5pin/3pin XLR female)
2x PoE etherCON/RJ45(10/100/1000M)
Two ethernet port work as network switch
4 x Network signal LEDs
Type-C Power In
Power Supply: Type-C 5V,PoE/802.3at
Power: 5W
Product Dimension: 147x112x48mm
Net Weight: 0.8kg
Package: 1pc carton
IP Rate: IP 65
Work Temperature:-10°C ~ 40°C
Power Supply: Type-C 5V,PoE/802.3at
Power: 5W
Product Dimension: 147x112x48mm
Net Weight: 0.8kg
Package: 1pc carton
IP Rate: IP 65
Work Temperature:-10°C ~ 40°C
